2024 OMEN
Geometry & Specs.
Frame Weight: Medium 5 LBS
Frame Sizes (CM): S // M // L
Top tube length (CM): S-53.8 // M-55.5 // L-58
Seat Tube C-T (CM): S-45.7 // M-46.5 // L-50
Chainstay Length (MM): 385
Head tube length (MM): S-110 // M-117 // L-127
Head tube Angle: S-73.25º // M-74º // L-74.25
Seat Tube Angle: S-74.5º // M-74º // L-73.5º
(MAX) Tire Clearance: S-43C // M-43C // L-43C
Seatpost Dia. (MM): 27.2
Seat Tube O.D. (MM): 31.8
Headset Type: 1-1/8" Threadless Integrated, 45ºX45º SPC*
B.B. Shell Width (mm): 68
B.B. Type: English
B.B Drop (mm): 35
Rear Hub Spacing (mm): 120
Wheel Size: 700C / 650B
2024 OMEN FITS ANY TRACK CRANKSET WITH UP TO A 48T CHAINRING
Material: True Temper, 4130 Chromoly
